État de disponibilité: | |
---|---|
Disponible Dimension Gamme | |||||||||||||
OD (mm/pouces) | Mur épaisseur (SCH) | ||||||||||||
10 | 20 | 30 | MST | 40 | 60 | XS | 80 | 100 | 120 | 140 | 160 | XXS | |
21.3 (1/2'') | √ | √ | √ | √ | √ | √ | √ | √ | |||||
26.7 (3/4'') | √ | √ | √ | √ | √ | √ | √ | √ | |||||
33.4 (1'') | √ | √ | √ | √ | √ | √ | √ | √ | |||||
42.2 (1 1/4'') | √ | √ | √ | √ | √ | √ | √ | √ | |||||
48.3 (1 1/2'') | √ | √ | √ | √ | √ | √ | √ | √ | |||||
60.3 (2'') | √ | √ | √ | √ | √ | √ | √ | √ | |||||
73 (2 1/2'') | √ | √ | √ | √ | √ | √ | √ | √ | |||||
88.9 (3'') | √ | √ | √ | √ | √ | √ | √ | √ | |||||
101.6 (3 1/2'') | √ | √ | √ | √ | √ | √ | |||||||
114.3 (4'') | √ | √ | √ | √ | √ | √ | √ | √ | √ | ||||
141.3 (5'') | √ | √ | √ | √ | √ | √ | √ | ||||||
168.3 (6'') | √ | √ | √ | √ | √ | √ | √ | √ | |||||
219.1 (8'') | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ |
273 (10'') | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ |
323.8 (12'') | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ |
355.6 (14'') | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | |
406.4 (16'') | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | |
457 (18'') | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | |
508 (20'') | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | |
559 (22'') | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | ||
610 (24'') | √ | √ | √ | √ | √ | √ | √ | √ | |||||
660 (26'') | √ | √ | √ | ||||||||||
711 (28'') | √ | √ | √ | √ | √ | ||||||||
762 (30'') | √ | √ | √ | √ | √ | ||||||||
813 (32'') | √ | √ | √ | √ | √ | √ | |||||||
864 (34'') | √ | √ | √ | √ | √ | √ | |||||||
914 (36'') | √ | √ | √ | √ | √ | √ |
Disponible Dimension Gamme | |||||||||||||
OD (mm/pouces) | Mur épaisseur (SCH) | ||||||||||||
10 | 20 | 30 | MST | 40 | 60 | XS | 80 | 100 | 120 | 140 | 160 | XXS | |
21.3 (1/2'') | √ | √ | √ | √ | √ | √ | √ | √ | |||||
26.7 (3/4'') | √ | √ | √ | √ | √ | √ | √ | √ | |||||
33.4 (1'') | √ | √ | √ | √ | √ | √ | √ | √ | |||||
42.2 (1 1/4'') | √ | √ | √ | √ | √ | √ | √ | √ | |||||
48.3 (1 1/2'') | √ | √ | √ | √ | √ | √ | √ | √ | |||||
60.3 (2'') | √ | √ | √ | √ | √ | √ | √ | √ | |||||
73 (2 1/2'') | √ | √ | √ | √ | √ | √ | √ | √ | |||||
88.9 (3'') | √ | √ | √ | √ | √ | √ | √ | √ | |||||
101.6 (3 1/2'') | √ | √ | √ | √ | √ | √ | |||||||
114.3 (4'') | √ | √ | √ | √ | √ | √ | √ | √ | √ | ||||
141.3 (5'') | √ | √ | √ | √ | √ | √ | √ | ||||||
168.3 (6'') | √ | √ | √ | √ | √ | √ | √ | √ | |||||
219.1 (8'') | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ |
273 (10'') | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ |
323.8 (12'') | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ |
355.6 (14'') | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | |
406.4 (16'') | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | |
457 (18'') | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | |
508 (20'') | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | |
559 (22'') | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | ||
610 (24'') | √ | √ | √ | √ | √ | √ | √ | √ | |||||
660 (26'') | √ | √ | √ | ||||||||||
711 (28'') | √ | √ | √ | √ | √ | ||||||||
762 (30'') | √ | √ | √ | √ | √ | ||||||||
813 (32'') | √ | √ | √ | √ | √ | √ | |||||||
864 (34'') | √ | √ | √ | √ | √ | √ | |||||||
914 (36'') | √ | √ | √ | √ | √ | √ |
Chimique Exigences | |||
C% | Mn% | P, maximum % | S, maximum % |
0,06-0,18 | 0,27-0,63 | 0.035 | 0.035 |
A 179 tubes d'échangeur de chaleur et de condenseur en acier à faible teneur en carbone étirés à froid sans soudure
ASTM | UNS NO. | CORÉE/JAPONS | ALLEMAND | BRITANNIQUE | BELGE | FRANÇAIS | ITALIEN | |||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Symbole KS/JIS | Numéro KS/JIS | Concernant | Type DIN | VACARME | Matériel | Concernant | BS | Catégorie BS | Concernant | Type NBN | Catégorie NBN | Concernant | AF | NF | Concernant | Type UNI | UNI | Concernant | ||
ASTMA179 | K01200 | STBH 340 / STB 35 | D3563 / G3461 | Rue 35.4 | 1629 | 1.0309 | 3606 | CSA 320 | D 37-2 | 629 | (3b) | TU 37 C | A49-215 | (3a) | C14 | 5462 | ||||
Rue 35.8 | 17175 | 1.0305 | Plus DIN 2391 Gutegard C.NBK |
Chimique Exigences | |||
C% | Mn% | P, maximum % | S, maximum % |
0,06-0,18 | 0,27-0,63 | 0.035 | 0.035 |
A 179 tubes d'échangeur de chaleur et de condenseur en acier à faible teneur en carbone étirés à froid sans soudure
ASTM | UNS NO. | CORÉE/JAPONS | ALLEMAND | BRITANNIQUE | BELGE | FRANÇAIS | ITALIEN | |||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Symbole KS/JIS | Numéro KS/JIS | Concernant | Type DIN | VACARME | Matériel | Concernant | BS | Catégorie BS | Concernant | Type NBN | Catégorie NBN | Concernant | AF | NF | Concernant | Type UNI | UNI | Concernant | ||
ASTMA179 | K01200 | STBH 340 / STB 35 | D3563 / G3461 | Rue 35.4 | 1629 | 1.0309 | 3606 | CSA 320 | D 37-2 | 629 | (3b) | TU 37 C | A49-215 | (3a) | C14 | 5462 | ||||
Rue 35.8 | 17175 | 1.0305 | Plus DIN 2391 Gutegard C.NBK |
Mécanique Propriétés | |
Traction force, min, ksi [MPa] | 47 [325] |
Rendement force, min, ksi [MPa] | 26 [180] |
Élongation dans 2 dans. ou 50 mm, min, % | 35 |
Mécanique Propriétés | |
Traction force, min, ksi [MPa] | 47 [325] |
Rendement force, min, ksi [MPa] | 26 [180] |
Élongation dans 2 dans. ou 50 mm, min, % | 35 |
